BALBOA CONTROLLER SIBP601X 3KW-(56539)

SIBP601X 240volt Output Sockets
CPUMP: Circulation Pump (Must be used if Pump 1 1Spd)
PUMP 1: 1Spd Pump or 2Spd Pump
PUMP 2: 1Spd Pump
BLOWER: Blower
240V: This outlet has a constant 240volts and is not switchable
O3/UV: This outlet is only to be used with an ozone system

SIBP601X Low Voltage
2 x Touchpad Outlets
1x AUX
1 x Light
1 x Wifi Port

SIBP601X Features
- In heater temp sensors
- Max Temp 40 degrees
- Adjustable Filtration
- Heater Modes (Ready & Rest)
- Wifi Interface
- Programmable Load Shedding

• Compatibility: It is compatible with Balboa TP series topside panels (e.g., TP400, TP600, TP800, TP900) and SpaTouch touchscreen panels, which are sold separately.

Controller Specifications
Heater Wattage: 3000w
Max Current: 32amp
Power Lead: Hard Wired
Power Lead Length: N/A
Heater Unions: 50mm

Controller Dimensions
Length: 382mm
Height: 275mm
Width: 110mm
Weight: 3.8kg

Touchpad sold separately.
ACONBP601x
