Balboa Pump 2HP-1.65KW 1SP-230V/50Hz-(1023130)

Product Description

The Balboa Spa Jet Pump 1023130 is a single-speed spa jet pump designed to deliver dependable water flow and strong jet performance in Balboa-equipped hot tubs and spas.

Originally supplied across a wide range of spa brands, this pump features a robust 56-frame motor, durable wet-end construction, and 2- suction and discharge plumbing connections. It is engineered for consistent operation, supporting effective hydrotherapy massage while maintaining reliable circulation through the spa-s jet system.

This model has since been superseded by newer Balboa Ultimax / Ultima / Vico single-speed jet pumps, which are the recommended replacements when servicing spas originally fitted with part number 1023130.

Technical Information?ÿ

• Manufacturer: Balboa Water Group
• Part Number: 1023130
• Pump Type: Spa / Hot Tub Jet Pump
• Speed: Single speed
• Voltage: 230-240-V AC
• Frequency: 50 / 60-Hz (market dependent)
• Input Power: Approx. 1700-W
• Motor Frame Size: 56 Frame
• Horse Power Rating: 2HP
• Plumbing Connections:
  • Suction: 2- female buttress thread
  • Discharge: 2- female buttress thread
• Union Outside Diameter: approx. 78-79-mm
• Discharge Orientation: Side discharge (orientation varies by spa model)
• Motor Type: TEFC (Totally Enclosed Fan Cooled)
• Protection: Internal thermal overload protection

Construction & Quality Features

• Carbon ceramic mechanical seal with Viton?? elastomers
• Chemical-resistant wet-end housing
• Heavy-duty motor designed for spa environments
• Built to meet international safety and performance standards (model-dependent certifications)

Replacement & Compatibility Information

• Replaces / Superseded by: Balboa Ultimax / Ultima / Vico single-speed jet pumps
• Common replacement references include newer Balboa part numbers such as 1023520, 1038301, 1038400, 5235210-S (depending on configuration).

Suitable for many spas using Balboa control systems and 2- jet plumbing.
Always confirm voltage, plumbing size, and discharge orientation before ordering.
